HK-968-LASER 激光全自动高速封边机
Laser fully automatic high-speed edge banding machine
一机两用，无懈可“激”！
激光封边模式和传统涂胶封边模式可以一键切换
履带输送和发射器速度1：1匹配，高速封边压料稳，不伤板
One machine can be used for two function，impeccable and exciting！
The laser edge banding mode and the traditional glued edge banding mode can
be switched with one click
The belt conveyor and launcher speed match 1:1,and the high-speed edge sealing
and pressing are stable and will not damage the board.
技术参数
| 型号 | Model | HK 968 LASER |
| 外形尺寸 | Overall dimensions | 12000*1200*1600mm |
| 封边带宽度 | Edge banding width | 10-60mm |
| 整机重量 | Overall weight | 6T |
| 封边带厚度 | Edge banding thickness | 0.4-3mm |
| 总功率 | Total power | 30kw |
| 抛光电机功率 | Polishing | 0.18*4 |
| 输送带电机 | Conveyor belt motor | 7.5kw |
| 额定电压 | Rated voltage | 380V 50HZ |
| 工件最小长度 | Minimum length of workpiece | ≥150mm |
| 额定气压 | Rated air pressure | 0.7MPA-0.9MAP |
| 工件最小宽度 | Minimum width of workpiece | ≥50mm |
| 工件输送速度 | Minimum conveying speed | 20-25-30m/min |
| 系统 | System | 汇川（Inovance） |
| 触摸屏 | Touch screen | 智能工控一体机（Intelligent industrial control screen） |
